MIL DTL 38999 Series Ⅰ Circular Connector Olive Green Cadmium Shell Finish Featuring Crimp Contact Type for Performance.MS27656T23B55SN

Part Number:MS27656T23B55SN

Product Description:

The MIL-DTL-38999 Series 1 connector is a high-performance circular connector designed to meet the demanding requirements of military, aerospace, and industrial applications. This connector is renowned for its durability, reliability, and ability to maintain secure electrical connections in the harshest environments. One of the key features of the MIL-DTL-38999 Series 1 is its bayonet coupling mechanism, which ensures quick mating and unmating while providing a robust and vibration-resistant connection. This makes it an ideal choice for applications where secure and rapid connectivity is critical.

The MS27656T23B55SN is a specific part number within the MIL-DTL-38999 Series 1 family, representing a connector with a unique combination of insert arrangement and electrical characteristics. This particular model features an insert arrangement of 23-55, which denotes a layout designed to accommodate a specific number of contacts in a compact and efficient configuration. This insert arrangement supports a variety of wiring and signal transmission needs, making the connector versatile for different system designs.

Electrical performance is a critical aspect of the MIL-DTL-38999 Series 1 connectors, and the MS27656T23B55SN is rated to handle a current of up to 5 amperes. This current rating ensures that the connector can support moderate power loads and signal transmission without compromising safety or performance. Coupled with a voltage rating of 500 volts, the connector is well-suited for applications requiring reliable power delivery and signal integrity under various operational conditions.

The contacts within the MIL-DTL-38999 Series 1 connector are made from high-quality copper alloy, a material known for its excellent electrical conductivity and mechanical strength. This contact material ensures low resistance and efficient signal transfer, which is essential for minimizing energy loss and maintaining high system performance. Additionally, the contacts are designed for crimp termination, providing a secure and mechanically stable connection to the wires. Crimp contacts are preferred in many military and aerospace applications due to their reliability and resistance to environmental stresses such as vibration and temperature fluctuations.

Aside from its electrical and mechanical features, the MIL-DTL-38999 Series 1 connectors, including the MS27656T23B55SN, are engineered to withstand environmental challenges such as moisture, dust, and extreme temperatures. The robust construction and bayonet coupling system contribute to the connector's ability to maintain consistent performance even in rugged field conditions. This makes it a trusted component in mission-critical systems where connector failure is not an option.

In summary, the MIL-DTL-38999 Series 1 connector, exemplified by the MS27656T23B55SN model, offers a reliable, high-quality solution for electrical interconnections in demanding environments. Its bayonet coupling mechanism facilitates quick and secure mating, while the 23-55 insert arrangement provides versatile contact configurations. With a current rating of 5 A and a voltage rating of 500 V, along with copper alloy crimp contacts, this connector meets rigorous industry standards for performance and durability. Whether used in military aircraft, industrial machinery, or aerospace systems, the MIL-DTL-38999 Series 1 connector ensures dependable connectivity and long-lasting service life.

Features:

• Product Name: MIL-DTL-38999 Series Ⅰ
• Insert Arrangement: 23-55
• Gender: Square Flange Receptacle
• Shell Size: 23
• Operating Temperature Range: -55°C To +125°C
• Features Crimp Contacts for secure and reliable connections
• Designed in accordance with MIL-DTL-38999 Series Ⅰ standards

Technical Parameters:

Applications:

The KAIDA MIL-DTL-38999 Series 1 connector, model number MS27656T23B55SN, is a high-performance circular connector designed for demanding military, aerospace, and industrial applications. Manufactured in China, this connector features a robust Olive Green Cadmium shell finish that ensures superior corrosion resistance and durability in harsh environments. With a shell size of 23 and 55 crimp contacts, the MS27656T23B55SN is engineered to provide reliable electrical connections with a current rating of 5 A per contact, making it suitable for complex wiring systems requiring secure and stable connectivity.

This connector is widely used in applications where reliability and ruggedness are paramount. The MIL-DTL-38999 Series 1, including the MS27656 model variants, is commonly employed in military vehicle communication systems, avionics, and ground support equipment. Its circular design and crimp contacts make it ideal for environments with significant vibration, shock, and exposure to contaminants, ensuring consistent performance under extreme conditions. The MS27656T23B55SN connector is also favored in aerospace applications for connecting critical instrumentation and control circuits due to its resistance to electromagnetic interference and environmental sealing capabilities.

In addition to military and aerospace, this connector is suitable for use in industrial automation and heavy machinery where robust electrical connections are essential. The 55-contact configuration allows for multi-signal transmission within a single connector, reducing wiring complexity and improving system reliability. The crimp contacts ensure secure termination of wires, enhancing electrical conductivity and mechanical retention, which is vital in high-vibration scenarios.

Overall, the KAIDA MS27656T23B55SN MIL-DTL-38999 Series 1 connector is an excellent choice for applications requiring a durable, high-density circular connector with dependable crimp contacts and a protective Olive Green Cadmium shell finish. Its versatility and rugged design make it suitable for use in military, aerospace, and industrial sectors where dependable electrical connections are critical to operational success.

Customization:

KAIDA offers product customization services for the MIL-DTL-38999 Series Ⅰ connectors, specifically the MS27656T23B55SN model. This connector, made in China, features a shell size 23 with an insert arrangement of 23-55, designed to meet rigorous military standards. The contact type is crimp, ensuring reliable and secure connections with high-quality crimp contacts. The shell finish is Olive Green Cadmium, providing excellent corrosion resistance and durability. With a voltage rating of 500V, this MIL-DTL-38999 Series Ⅰ connector is ideal for demanding applications requiring robust performance and customization options to meet specific customer requirements.

Support and Services:

Product Technical Support and Services for the MIL-DTL-38999 Series 1 connectors include comprehensive assistance to ensure optimal performance and reliability. Support services encompass detailed product documentation, application guidelines, and troubleshooting resources tailored to the MIL-DTL-38999 Series 1 specifications.

Technical support teams provide expert guidance on connector selection, installation procedures, maintenance practices, and compatibility with various cable and equipment types. Services also include customized solutions to meet specific operational requirements and environmental conditions.

Additional support features include product training sessions, testing and qualification services, and access to engineering expertise for design and integration challenges. These services are designed to help customers maximize the lifespan and functionality of their MIL-DTL-38999 Series 1 connectors in demanding military and aerospace applications.

Packing and Shipping:

The MIL-DTL-38999 Series 1 connectors are packaged to ensure maximum protection during transportation and storage. Each connector is individually packaged in a sealed plastic bag to prevent contamination and damage. The connectors are then placed in sturdy, cushioned boxes designed to absorb shocks and vibrations.

For shipping, the packaged connectors are consolidated into larger cartons with appropriate cushioning materials to avoid movement and impact. All packages are clearly labeled with product details, handling instructions, and identification markings in accordance with MIL-STD-129 standards.

The packaging and shipping process complies with military specifications to guarantee that the MIL-DTL-38999 Series 1 connectors arrive at their destination in optimal condition, ready for immediate use in critical applications.
